  Home >  Products & Services >  Pipe Systems and Roofings >  Thermoplastic Pipe Systems >  PPR >  Hot and Cold Water Supply & Distribution
  POLYDEX - PPR PIPE SYSTEM FOR HOT AND COLD WATER SUPPLY AND DISTRIBUTION



Polydex piping systems can be used for distribution systems in housing, administration and community buildings as well as for industrial installations. Polydex is designed for transport of cold and hot water. It is also used for the distribution of compressed air. Polydex is the first complete PPR piping system in Pakistan that conforms to international quality and safety standards.
In order to take advantage of its chemical resistance and other system properties and use of system for transport of other liquids, gaseous or solid media - an individual assessment of any such case would be needed.

Applications
Potable water pipe networks for cold and warm water installations i.e. in residential buildings, hospitals, hotels, office and school buildings, ships, etc.
House connections, boiler connections, high rises, water point connection
Rainwater utilisation systems
Swimming Pools
Hospitals and many more

Advantages
Potability
Welding Capability
Versatility
Noise Free
Resistant to Frost
Resistant to Abrasion and Corrosion
Energy Saving and Environmentally Friendly
Low Electrical Conductivity
Low Heat Conductivity
Fitness for Use in Seismic Areas

Range
Outer diameter
Pipes & fittings in 20mm, 25mm, 32mm, 40mm, 50mm, 63mm, 75mm, 90mm & 110mm in length of 4 meters.

Specifications
Pipes: DIN 8077-8078 with a pressure rating of PN 20
Fitting: DIN 16962.
Polydex fittings carry a mark 'Ekoplastik' (EK on fittings).
Note: PN 10 pipes can also be supplied against specific requirements.

Our nationwide network of sales offices and technical support staff is always ready to help. If you have any queries or require more information please contact us.
